AC Ev chargers with dual sockets with 2*22kw Ev charger for commercial use

AC Ev chargers with dual sockets with 2*22kw Ev charger for commercial use

Introducing a versatile and efficient dual-socket, floor-standing AC EV charger featuring two 22kW outputs, perfect for meeting the growing demand for electric vehicle charging. With a MID-certified meter, this charger ensures accurate billing, making it a reliable choice for any location.



Its IP65 weatherproof protection allows for seamless outdoor installation, designed to withstand various environmental conditions. The charger supports multiple payment options, including RFID, QR codes, and credit cards, providing convenience for users. Additionally, its OTA-upgradable feature enables remote management, simplifying maintenance and updates.



This charging solution can effectively accommodate two electric vehicles simultaneously, making it an excellent addition for hotels, offices, and public parking lots. Enhanced with built-in protections against overcurrent, surges, and residual current, this charger prioritizes safety and reliability for both users and the equipment. Embrace the future of charging with this state-of-the-art EV charger!

Product Specifications - Dual socket Ev charger
Specification
Model 7.4KW*2 22KW*2
Electrical Properties
Voltage 220-240V 380-400v
Output Current 32A1P 32A/3P
Frequency 50Hz-60Hz 50Hz-60Hz
Output Power 7.4KW*2 22KW*2
Residual Current Protection Type B (AC 30mA + DC 6mA)
Design
Emergency Stop Button Yes
Display 4.3” LCD Touch Screen
RFID Function Yes
Charging Outlet 2 charging sockets(Can be customized) + 5M Length Charging cable
Power Incoming line 1M Length
Housing Material PCV0 for Outdoor
Front Panel PC
Installation Method Wall-mount/Floor-stand
Network Gateway Wifi
Communication Protocol OCPP 1.6J&2.0, 4G/WIFI
Warranty 2 Years
Environmental Performance
Protection Level IP55
Working Altitude <2000M
Application Site Indoor/Outdoor
Working Temperature -30℃~+50℃
Working Humidity 5%-95%, No Condensation
Atmospheric Pressure 80kPa – 101kPa
Packing Details
Product Dimension 46*41*21cm 46*41*21cm
Product Weight 8 Kg 9 Kg
Optional Config
Dynamic Loading Balance RS485 Meter or Local Junction box (optional)
Energy Meter MID Certified
Network Gateway Ethernet/4G
