This CCS2 to CCS1 Dc charging adapter allows you to charge electric vehicles at CCS2 charging stations with EV imported from USA. The adapter is rated at 300kW. The adapter is compatible with all EVs with a CCS1 port. If you have compatibility concerns, feel free to contact us.
Connect CCS1 (US Standard) EVs to CCS2 (EU Standard) DC Fast Chargers. Rated for 250A / 1000V DC. Features passive protocol bridging and IP54 protection for outdoor fleet operations.
| Plug and charge, zero operation threshold |
Portable convenient installation |
Full-interface compatible, no vehicle model restrictions |
 |
 |
 |
Parameters
|
Item |
CCS2-CCS1 DC AC Ev charging adapter |
|
Rated Current |
250/300A |
|
Withstand Voltage |
2000v |
|
Rated frequency |
50/60Hz |
|
Machinical life |
20000times |
|
Insulation Resistance |
＞1000MΩ（DC500V） |
|
Withstand Voltage |
3200V |
|
Contact Resistance |
0.5mΩ Max |
|
Atmospheric Pressure |
80KPA ~ 110KPA |
|
Relative Humidity |
5%~95% |
|
Operating Temperature |
-30°C~+60°C |
|
Storage Temperature |
-40°C~+70°C |
|
Protection Degree |
IP55 |
|
Weight |
0.8KG |
|
Standard |
IEC 61851-1:2010 EN 61851-1:2011 IEC 61851-22:2002 EN 61851-22:2002 |
|
Certification |
TUV,CE Approved |
|
Protection |
1.Over and under frequency protection 2. Over Current Protection 3.Leakage Current Protection (restart recover） 4. Over Temperature Protection 5.Overload protection (self-checking recover) 6. Ground Protection and Short circuit protection 7.Over voltage and under-voltage protection 8. Lighting Protection |
Product Feature
Adapter CCS Combo 2 to CCS Combo 1 – DC Fast Charging Only (250 kW Max)
Charge your US-imported EV in Europe quickly and securely.
This CCS2 to CCS1 adapter is designed exclusively for DC fast charging, enabling North American electric vehicles to use CCS2 public fast-charging stations across Europe with seamless compatibility and high power delivery.
Dual-Locking Security System
Unlike standard adapters, this model features a double locking mechanism for maximum safety.
• The vehicle side locks to your CCS1 port as usual, preventing accidental removal during charging.
• The charger side (CCS2) also locks in place once the adapter is connected and the vehicle confirms charging, securing the CCS2 plug and preventing unintended disconnections or theft.
High-Power DC Charging
Supports up to 250 kW DC for rapid energy transfer. An integrated temperature kill switch automatically pauses charging if internal heat reaches 85 °C, resuming once the adapter cools for safe, reliable operation.
Simple Plug-and-Charge
Just connect the adapter to the CCS2 charging plug first, then attach it to your car’s CCS1 port. No configuration or setup is required—charging starts instantly.
Wide Vehicle Compatibility
Works with all CCS1 (J1772 Combo) electric vehicles, including Tesla (with CCS1), Volkswagen ID.4, Ford Mustang Mach-E, Rivian, Hyundai IONIQ 5/6, Kia EV6, Chevrolet Bolt EV, Audi e-tron, Porsche Taycan, Fisker, and many others.
Suitable for North American EV
